EN-6500

Features:

• Digital voice evacuation system all in one amplifier.
• Specifications meet the standards of BS EN54-32 & EN608409.
• EN54-16 standards certificate is under taken.
• Built-in 500W 6 zone class-D amplifier.
• Integration of EVAC controller, paging system, PA system & BGM system together.
• Built-in two separate players for EVAC and alert voice message by SD card.
• Built-in 6 zone AB speaker line low impedance supervision.
• Built-in amplifier auto changeover into standby when fault.
• With external amplifier input to expansion the power.
• Capacity of connection 32 units remote microphones.
• Red button EVAC message push to activate with priority except fireman microphone.
• 6 zone speaker outputs with separate zone volume control (ATT).
• 6 zone separate indicator for EVAC, fault, music/paging & select.
• System indicators of AC, DC, fault and indicators for EVAC, alert & fireman microphone.
• Zone capacity of 120 zones by cascaded 19 routers.
• With 8 programmable control inputs and 8 programmable control outputs for voice evacuation system.
• With Fault, EVAC outputs and Reset input for third party system integration.
• With fireman microphone of highest priority.
• Priority level: fireman mic, EVAC, input 1, remote microphone, timer & BGM.
• Two combo inputs for mic/line, 4 line inputs and one REC output.
• Two RJ45 ports for router, two RJ45 for remote microphone input and two RJ45 for LAN/WAN/Internet network.
• IP network module for optional to buy.
• AC 230V and DC24V battery input. Auto switch into the battery backup when AC fails.
